The Story

Radxa´s ROCK3 Compute Module (Radxa CM3) is a SoM (System on Module)

Based on the Rockchip RK3566 SoC in a small form factor of 55mm x 40mm, it integrates CPU/PMU/DRAM/STORAGE and Wireless.

Radxa´s CM3 offers an out of the box, cost-effective solution for countless applications. It as well simplifies and accelerates new product developments.

Overview of features:

Quad core 64 bit High Performance Solution

Radxa CM3 is powered by the Rockchip RK3566 SoC, a 64bit Quad Cortex A55 low power core with up to 1.8Ghz. It comes with a maximum of 8GB RAM and up to 128GB eMMC storage.

With a simple carrier board (a 2 layer base board is sufficient to provide access to all functions of the SoM), the engineers can quickly develop solutions and prepare the boards for production.

Rich interfaces

I2C, SPI, UART, ADC, PWM, GPIO, Ethernet, CAN, PDM, USB2, USB3, I2S, MIPI,
SATA, eDP interfaces are available as well as PCIe 2.0 high bandwidth buses.

Display Capability

The Dual Video Out put Processor supports dual display output to any two of HDMI, eDP, MIPI, DP, with a resolution of up to 4K x 2K and one 2.5k

Powerful multimedia utility support

4K VP9 and 4K 10bits H264/H265 video decoding, up to 60FPS

multiple 1080P video formats decoding including VC-1, MPEG-1/2/4, VP8

1080P encoding to H.264, VP8 formats

Small size and low power

55mm x 40mm form factor and industry compatible 3 x 100PIN board to board connectors save board space and provide standardized interfaces and save board space.

Multiple OS support

Ubuntu 20.04 / Debian 10 / Buildroot / Android

Open documents and source code

Source code, documents, tools & utilities are freely available, community and commercial support are available to help you put your prototype into production

Widely used in various applications

Perfect SoM for Robotics, HMI, Vending Machines, Smart Home, IOT Gateway, Industrial Control, Medical Equipment etc.

Detailed technical specs:

Processor:

Rockchip RK3566, Quad core Cortex-A55 (ARM v8) 64-bit SoC @1.8GHz

Memory:

1GB, 2GB, 4GB or 8GB LPDDR4 (depending on variant)

Connectivity:

- Optional wireless LAN, 2.4GHz and 5.0GHz IEEE 802.11b/g/n/ac
wireless, Bluetooth 5.0, BLE with onboard and external antenna options
- Onboard Gigabit Ethernet PHY
- 1 × USB 2.0 port ( highspeed ), 1 x USB 3.0 port ( 5Gbps )
- 1 × PCIe 1-lane Host, Gen 2 ( 5Gbps )
- 2 x SATA ports, one shared with USB 3, one shared with PCIe
- 50 × GPIO support

Video:

- 1x HDMI up to 4K x 2K@60HZ
- 1x eDP four lanes, 2.7Gps per lane
- 2x MIPI DSI four lanes, 1.6Gbps per lane

Audio:

- LINEOUT
- I2S
- PDM, support mic array

Multimedia:

- VP9/H.264/H.265 decode 4K@60HZ
- H.264/H.265 encode 1080P@100HZ
- OpenGL ES 3.2/OpenCL 2.0/Vulkan 1.1 GPU

Input power: 5V DC

Connector: 3x 100P 0.5mm pitch B2B connector

Dimension: 55 mm × 40 mm

ROCK3 CM will remain in production until at least Sep 2029

IMPORTANT PURCHASE INFORMATION:

Because of the high number of variants only a few models will be available from stock. (we will make sure our stock levels are always sufficient for immediate supply) If you plan to purchase any other model the MOQ will be 100 pieces.

FOCUS SKU´s:

1GB/8eMMC/WIFI RM116-D1E8W2

2GB/16eMMC/WIFI     RM116-D2E16W2

4GB/32eMMC/WIFI     RM116-D4E32W2

8GB/64eMMC/WIFI   RM116-D8E64W2
