$6.27The Story
Rockchip RK3308BS based tiny yet feature rich SBC
-
Rockchip RK3308BS Quad Cortex-A35 64bit SOC @1.3GHz
- 256 / 512MB DDR3 RAM variants
- 2GB / 4GB or 8GB onboard eMMC
- USB 2.0 OTG (via 4-pin MX1.25mm connector)
- USB 2.0 HOST (via 4-pin MX1.25mm connector)
- 10/100Mbit Ethernet (via 4-pin MX1.25mm connector)
- 802.11 b/g/n Wifi (4) + Bluetooth 5.0 with external antenna connector
- Reset button
- Maskrom button
- TF card slot
- 40 pin GPIO header
- I2C x4
- PWM x3
- SPI x2
- UART x3
- I2S0 x1
- 5V DC power in x2
- 3.3V DC power in x2
- ARMv8 Instruction Set
- Debian, Ubuntu Linux support
- Hardware access/control library for Linux
- Power demand idle: 0.5W / full load: <=5W
- CPU does only need heat management when operated continuously under high load or high environmental temperature!
- Operating temperature 0-50°C
- Dimensions 65x30mm
FURTHER DETAILS ON ROCK S0 FROM STARTER TO DEVELOPER
Main documentation page on ROCK S0
